Formwork [Layout] Optimizer

The Optimizer exports layouts in DXF and DWG formats compatible with AutoCAD and Revit, allowing structural engineers to review and approve AI-generated layouts within their existing CAD environment without re-drawing. BOM outputs include manufacturer part numbers for major aluminium formwork systems (PERI, DOKA, Meva, Hünnebeck), enabling direct procurement integration. The PDF installation guide generated for field crews is structured as a step-by-step sequence synchronized with the layout drawing, replacing handwritten field notes. For GCs using Procore, the output package uploads directly to the project's RFI and submittal log.

For a structural engineering firm or formwork contractor with standard commercial building project types, implementation takes 2–3 weeks. Week one covers blueprint format standardization (PDF, DWG, or IFC input types) and calibration of the AI's layout engine against 3–5 of your recently completed projects to validate output against your structural engineering standards. Week two is workflow integration: connecting to your CAD environment and procurement system. Week three is live deployment on an active project with engineering team review. The AI improves accuracy with each project processed, building a firm-specific training set over time.

The Optimizer needs structural drawings for the project: floor plans with slab dimensions, column grid, slab thickness, and opening locations; and structural specifications for concrete mix, design loads, and pour sequence where relevant. It also needs your formwork system's product data — panel dimensions, load ratings, and accessory specifications, either from standard manufacturer libraries pre-loaded in the system or uploaded for proprietary systems. Site-specific constraints (crane reach, access points, adjacent work restrictions) are entered by the engineer in a structured input form and factored into the layout optimization.

Construction firms using AI-optimized formwork layout report formwork planning time reducing from 3–5 days per floor plate to 4–8 hours, material utilization improving by 10–18% through optimized panel arrangement that reduces cut waste, and formwork-related RFIs decreasing by 30–40% as AI-generated layouts are more consistently code-compliant and complete. On a 10-story concrete building, these improvements typically represent $50,000–$150,000 in combined labor savings (engineering and field) and material cost reduction, depending on the complexity of the floor plate geometry.

Structural engineers and temporary works designers are the primary users — running the optimizer as the first step in formwork design rather than starting from a blank CAD file. Formwork contractors use it to rapidly produce layout proposals during the bidding phase when time is limited and the project is not yet awarded. Procurement managers use the BOM output to run competitive material sourcing across multiple formwork system suppliers. Site engineers and foremen use the generated installation guide directly on site, replacing informal handoffs from office engineering to field crew.
